Dissmann MEV-J 1000VDC Fuse , Ceramic Automotive Fuses For EV Charger

Dissmann | Global Expert Fuse for EV | HEV | Photovoltaic | Battery | Energy Storage Solutions
Contact Now
    Buy cheap Dissmann MEV-J 1000VDC Fuse , Ceramic Automotive Fuses For EV Charger from wholesalers

    Buy cheap Dissmann MEV-J 1000VDC Fuse , Ceramic Automotive Fuses For EV Charger from wholesalers
    • Buy cheap Dissmann MEV-J 1000VDC Fuse , Ceramic Automotive Fuses For EV Charger from wholesalers

    Dissmann MEV-J 1000VDC Fuse , Ceramic Automotive Fuses For EV Charger

    Ask Lasest Price
    Brand Name : Dissmann
    Model Number : MEV-J 1000VDC
    Certification : TUV
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1000000pcs
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    Dissmann MEV-J 1000VDC Fuse , Ceramic Automotive Fuses For EV Charger

    Dissmann MEV-J 1000VDC Fuse Ceramic Automotive Fuses for EV Charger made in China

    Dissmann MEV-J 1000VDC Fuse Ceramic Automotive Fuses for EV Charger made in China

    Basic information

    • The size and performance of bolt-on fast-acting fuse shall comply with JASO-D622, IEC60269 and UL248
    • Rated Voltage:DC1000V or lower; Rated Current:Optional
    • Protection Type:aR; Breaking Capacity:DC50kA
    • Comply with EU and China RoHS directives,
    • Meet the requirements of UL-248, ISO8820 and JASOD622

    Appearance and installation dimension of the fuse(mm)

    Dissmann MEV-J 1000VDC Fuse Ceramic Automotive Fuses for EV Charger made in China

    Dissmann MEV-J 1000VDC Fuse Ceramic Automotive Fuses for EV Charger made in China

    Dissmann MEV-J 1000VDC Fuse Ceramic Automotive Fuses for EV Charger made in China

    Dissmann MEV-J 1000VDC Fuse Ceramic Automotive Fuses for EV Charger made in China

    Dissmann MEV-J 1000VDC Fuse Ceramic Automotive Fuses for EV Charger made in China

    Product type that you can choose:

    MEV-J 1000VDC
    Product codeRated current AI²t(A²Sec)power consumption
    Pre-arcTotalW
    MEV-J-C20

    MEV-J-C21

    MEV-J-C30

    MEV-J-C31

    MEV-J-D23
    5014068013
    63250130015
    80510255020
    1001100520028
    1252000980032
    16041002000038
    20085004200044
    250130006000048
    300180009000053
    3152300011000060
    MEV-J-D20
    MEV-J-D30
    MEV-J-D23
    3502400012500070
    4003800019000080
    4505300026000085
    5006950034000095

    Service conditions

    Normal use conditions and parameter correction.

    The fuse operates under the following normal conditions of use, without additional correction.

    When the normal use conditions are exceeded, if they are within the allowable use conditions, some parameters may need to be corrected or consulted. If the scope of allowable use conditions is exceeded, our company should be consulted and the work adaptability evaluation and test of the conditions should be carried out.

    It is recommended that the current value of long-term current flow should not be greater than 80% of the rated current.
